This mechanical keyboard features a sturdy aluminum frame
StackedTKL
An affordable entry point into the DIY keyboard hobby
The StackedTKL is a continuation of our Stacked series a line of budget oriented stacked acrylic keyboard kits from CannonKeys! This board is designed out of 3mm thick layered acrylic pieces, and has a very distinctive acrylic case sound.
We have a to help you put this kit together!
What's included
- 7 Layer Acrylic Keyboard Case
- 4 Layers Acrylic Keyboard Feet
- Clear bottom layer
- Clear feet layers
- 1.6mm FR4 plate
- M2x15 Brass Standoff x 10
- M2x6 Brass Standoff x 4
- M2x6 Stainless Hex Screw x 28
- 1 DevastatingTKL Solderable PCB
Colors Available
- Black, Clear, Frosted, Blue, and White
Addons Available
You will need a soldering iron, solder, and 1.5mm Hex Head Screwdriver to assemble this kit.
You will also need to purchase
-
- Up to 90 switches
- Be sure to purchase a keycap set with a 1.75U Right Shift Key
- - up to 4x2U and a 6.25U or 7U
- Left Shift, Enter, Right shift and Backspace all need a 2U stabilizer.
- The spacebar will need a 6.25U or 7U stabilizer depending on your selected layout
This mechanical keyboard provides stable key press and actuation
